TWO POST CLEAR FLOOR
TP15KCX
Two Post Clear Floor
- 15,000 lbs Capacity
- Symmetric Arms
- Rubber Door Guards
- Chain Drive Cylinders
- Dual Point Lock Release
- auto Arm Restraint System
- Spin Up Lift Pads
- Stackable Adapter Included
- Internal Hose routing
Specifications
| Lift Model | TP15KCX |
| Capacity | 15,000 lbs. |
| Height Overall | 179-3/8″ |
| Width Overall w/ Power Unit | 148-3/8″ |
| Max Lift Height | 76-1/2″ |
| Width Between Columns | 120-3/4″ |
| Min. Pad Height | 5″ |
| Drive Thru Clearance | 109-3/8″ |
| Lifting Speed | 45S |
| Asymmetric / Symmetric | Symmetric |
| Clear Floor / Floor Plate | Clear Floor |
| Short Arm Reach – min/max | 37″ – 52″ |
| Long Arm Reach – min/max | Same |
| Narrow Bay Setting | NA |
| Max Load Per Arm | 3,750 lbs. |
| Ship Weight | 2,575 lbs |
| Power | 220V – 20 AMP – 1 PH |
Flier
Manual
Accessories
TP12KFX/15KCX-SPNCA
TP12KFX/15KCX-GM19-SPNCA
Additional Information
